Active DisplayPort to HDMI Adapter, 4K@60Hz with LED Ring
Built around the ITE IT6563FN chipset, this locking DisplayPort adapter supports up to 4K@60Hz or 1080p@120Hz for compatible HDMI monitors, TVs and projectors.
4K@60Hz DisplayPort-to-HDMI conversion with a visible LED status ring
4K@60HzDetailed UHD output1080p@120HzSmooth Full HDIT6563FNActive conversionLED RingConnection indication
Correct direction and removal
One-way DisplayPort source to HDMI display only. It is not HDMI-to-DisplayPort. Press the locking DP connector’s release button before removal. Maximum output depends on the graphics source, adapter, HDMI cable and display.
| Input / Output | Locking DisplayPort male to HDMI female |
|---|---|
| Maximum modes | 4K@60Hz; 1080p@120Hz |
| Chipset / Indicator | ITE IT6563FN; LED status ring |
| Model / SKU | CP20A / CT-AV589-P02G4k60(R)-SG0.15 |
USE
- Connect DP to the source.
- Connect an HDMI cable and display.
- Select the HDMI input.
- Press the release button before unplugging.
COMPATIBILITY
For DisplayPort graphics sources and HDMI monitors, TVs and projectors.
USER SCENARIOS
- 4K office or creative monitor
- High-refresh Full HD display
- Conference-room HDMI screen
- Premium travel presentation kit
FAQ
Active? Yes.
LED purpose? Visible connection status.
Reverse direction? No.
GST invoice, India support and applicable warranty.
Check the signal path first.
Identify the source and display or capture device, check connector type and conversion direction, then connect and select the correct input. Choose a video mode supported by the complete setup.
Will I always get the maximum listed resolution?
Actual output depends on the source, receiving device, intermediate equipment, selected mode and the length or version you choose. Check any length-specific limits in the product details.
Which length or version should I select?
Use the product selector to choose the required option. Check that option against any model, connector, length or pack-size distinctions in the specifications before ordering.
